Description

RockBLOCK Plus is the field-ready version of RockBLOCK, built around the Iridium 9602 SBD transceiver and sealed for outdoor deployments.



Use it when you need low data satellite messaging from remote equipment, but don't want to design your own enclosure, antenna mounting, power conditioning, or external cabling. It's a good fit for data loggers, environmental sensors, buoys, field instruments, industrial assets, and other systems that need to send small payloads from places normal networks don't reach.



RockBLOCK Plus sends and receives Iridium Short Burst Data messages over a simple serial interface. It supports 340 byte mobile originated messages and 270 byte mobile terminated messages, making it best suited to compact telemetry, alerts, status updates, and commands.



The unit includes the modem, antenna, and power conditioning inside a sealed IP67 enclosure, with 9-30V DC input and RS-232 data. Choose RockBLOCK Plus when you want the proven SBD workflow of RockBLOCK in a package that is ready to mount outside.

Key Features

  • IP67-rated enclosure provides total ingress protection against dust and water submersion
  • Integrated antenna design eliminates the need for separate RF cabling or external antenna mounting
  • Standardized Iridium SBD messaging protocol for reliable two way data transmission
  • Built for remote, off-grid deployments with high impact resistant housing
  • Simplified mounting interface for installation on masts, vehicles, or structural frames
  • API-ready command structure supporting rapid system integration
  • Global, pole-to-pole coverage utilizing the Iridium Low Earth Orbit satellite network.

Tech Specifications

  • Satellite network: Iridium
  • Satellite service: Short Burst Data, SBD
  • Iridium modem: 9602 SBD transceiver
  • Message size: 340 bytes MO, 270 bytes MT
  • Data interface: RS-232
  • Power input: 9-30V DC
  • Power consumption: 450mA max, 100mA required
  • Antenna: integrated 1621 MHz tuned patch antenna
  • Enclosure: encapsulated outdoor housing
  • Waterproofing: IP67, submersible up to 1m for 30 minutes
  • Dimensions: 40 mm high, 137 mm diameter, plus cable
  • Weight: 300 g
  • Operating temperature: -40°C to +85°C
  • Storage temperature: -40°C to +85°C
  • Operating environment: <75% relative humidity
  • Message delivery: email or HTTP POST to your web service.

Cloudloop Platform

RockBLOCK Plus integrates seamlessly with the Cloudloop platform for unified data and fleet management.

Cloudloop Data handles the conversion of raw satellite packets into structured, usable formats for your specific applications, while the Subscription Manager provides a central interface to monitor hardware health, billing, and global usage across your entire deployed fleet.
Explore CloudloopCloudloop Developer Docs

Resources / Quick Links

RockBLOCK Plus

FP-GC-RB-PLUS-3M

$419.00
$419.00
Sale Sold out
Taxes included.
Cable Length
Inquire

Frequently Asked questions

Very. RockBLOCK Plus is a completely encapsulated design with a marine-grade kevlar cable, so it's at least IP67 (submersible for up to 30 minutes). Just don't expect it to send messages from underwater - all satellite devices need a clear view of the sky!

No. RockBLOCK Plus features an integrated antenna within the sealed enclosure. External antenna hardware is not required.

Airtime is purchased separately from the hardware.

When your RockBLOCK SBD device arrives, register it online at the RockBLOCK portal. You can buy message credits, manage your device, and start sending messages without speaking to sales.

If you prefer post-pay airtime, contact our team at hello@groundcontrol.com and we can switch your account over.

You can find PAYG and post-pay airtime rates at https://www.groundcontrol.com/products/iridium/short-burst-data-range/short-burst-data-service-plans/.
